10m Wide 1.5mm HDPE Geomembrane

1.Extra Wide Roll – 10m width reduces seams, speeding up installation and enhancing anti-seepage performance.

2.High Strength & Durability – 1.5mm thickness provides superior puncture, tear, and impact resistance.

3.Excellent Anti-Seepage – Advanced HDPE material ensures outstanding impermeability for ponds, landfills, and reservoirs.

4.UV & Chemical Resistance – Long-lasting performance under sunlight, acids, alkalis, and harsh environments.

5.Easy Installation – Fewer joints, reliable welding performance, and reduced labor cost.

Contact Now E-Mail Telephone WhatsApp

Product Details

When it comes to large-scale waterproofing and environmental protection projects, choosing the right geomembrane can make the difference between long-lasting success and costly failure. Among the wide range of options available, the 10m wide 1.5mm HDPE geomembrane stands out as one of the most reliable, efficient, and cost-effective solutions for engineers, contractors, and project owners. With its extra-wide design, durable thickness, and superior performance, this geomembrane has become the material of choice for critical applications such as landfills, reservoirs, tailings dams, aquaculture ponds, and industrial containment projects.

Extra Wide Roll – Faster Installation, Fewer Seams

One of the greatest advantages of the 10m wide HDPE geomembrane is its extra-wide roll format. Traditional geomembranes often come in narrower widths, which means more overlap seams are required during installation. Each seam not only adds installation time and cost, but also increases the potential risk of leakage if not welded properly.

By contrast, the 10m wide design dramatically reduces the number of seams across a project site. This leads to:

1.Faster and more efficient installation.

2.Lower labor and equipment costs.

3.Enhanced waterproofing performance due to minimized seam areas.

4.Reduced potential for seepage or system failure.

For large projects such as reservoirs or tailings ponds, this extra width provides a significant competitive advantage, helping contractors complete work ahead of schedule while ensuring higher quality results.

Superior Thickness for Strength and Durability

At 1.5mm thickness, this HDPE geomembrane delivers excellent mechanical strength. Thicker geomembranes are better equipped to resist punctures, tears, and impacts caused by sharp stones, construction machinery, or operational loads. This makes the product ideal for applications where soil settlement, heavy equipment traffic, or harsh environmental conditions are expected.

With its robust physical properties, the geomembrane ensures:

1.Long service life without frequent repairs.

2.Reliable performance under high pressure and stress.

3.Better protection against root penetration or animal damage.

In comparison with thinner liners, the 1.5mm HDPE geomembrane offers peace of mind for engineers who require long-term stability and safety.

Exceptional Waterproofing and Anti-Seepage Properties

The primary role of any geomembrane is to prevent seepage, and this product excels in that regard. Manufactured from high-quality HDPE virgin resin, the geomembrane has an extremely low permeability coefficient, making it an effective barrier against water, leachate, and other liquids.

This superior waterproofing capability is especially valuable in:

1.Landfills, where leakage prevention is critical to protect soil and groundwater.

2.Water reservoirs, ensuring efficient water storage without losses.

3.Mining operations, where tailings ponds must safely contain slurry and waste.

4.Aquaculture ponds, maintaining water quality and preventing contamination.

Whether used in civil engineering or industrial projects, the 10m wide 1.5mm HDPE geomembrane guarantees optimal anti-seepage performance.

UV and Chemical Resistance for Harsh Environments

In addition to strength and impermeability, this geomembrane is engineered for long-term durability in outdoor and chemically aggressive environments. Its HDPE formulation offers:

1.Excellent UV resistance, making it suitable for projects exposed to direct sunlight.

2.Superior chemical resistance, ensuring stability against acids, alkalis, salts, and various industrial effluents.

3.Outstanding weather resistance, with performance unaffected by heat, cold, or humidity.

This makes the geomembrane a versatile choice not only for standard waterproofing applications but also for demanding environments such as chemical plants, hazardous waste storage, and desert climates.

Easy Installation and Welding Performance

The 10m wide 1.5mm HDPE geomembrane is designed with installer convenience in mind. Despite its robust thickness, the product maintains excellent flexibility, making it easier to handle on-site. It is compatible with advanced hot wedge and extrusion welding techniques, which guarantee strong, reliable seam strength.

The combination of wide rolls, fewer seams, and reliable welding leads to a significant reduction in installation time, costs, and risks. Contractors benefit from smoother project execution, while project owners enjoy faster project delivery and long-lasting results.

Eco-Friendly and Safe Material

Another key advantage of this geomembrane is its environmental safety. Manufactured from 100% virgin HDPE, it is non-toxic, odorless, and free of harmful substances. This ensures that the geomembrane is safe for use in sensitive applications such as:

1.Fish ponds and aquaculture projects, where water quality and aquatic life must be protected.

2.Drinking water reservoirs, ensuring no contamination risks.

3.Agricultural irrigation projects, keeping soil and crops safe.

By choosing this geomembrane, project stakeholders can meet environmental regulations while promoting sustainable development.

Applications Across Industries

Thanks to its comprehensive performance advantages, the 10m wide 1.5mm HDPE geomembrane is widely used in:

1..Environmental engineering: Landfills, hazardous waste sites, leachate ponds.

2.Water resources management: Reservoirs, canals, dams, and irrigation systems.

3.Mining and energy: Tailings ponds, heap leaching pads, power plant ash storage.

4.Agriculture and aquaculture: Fish ponds, shrimp farms, biogas digesters.

5.Industrial containment: Chemical storage, oil refineries, wastewater treatment plants.

Its versatility makes it a one-stop solution for both public and private sector projects.

No.	Item	Unit	Index
1	Thickness	mm	0.30	0.50	0.75	1.00	1.25	1.50	2.00	2.50	3.00
2	Density	g/cm3	≧0.940
3	Tensile yield strength	N/mm	≧4	≧7	≧10	≧13	≧16	≧20	≧26	≧33	≧40
4	Tensile breaking strength	N/mm	≧6	≧10	≧15	≧20	≧25	≧30	≧40	≧50	≧60
5	Yield elongation	%	-	-	-	≧11
6	Break Elongation	%	≧600
7	Right-angle Tearing strength	N	≧34	≧56	≧84	≧115	≧140	≧170	≧225	≧280	≧340
8	Puncture strength	N	≧72	≧120	≧180	≧240	≧300	≧360	≧480	≧600	≧720
9	Carbon black content	%	2.0~3.0
10	Dispersion of carbon black	-	There is not more than one level 3 in 10 data, and level 4 and level 5 are not allowed to exist.
11	Oxidation induction time	min	≧60
12	Low temperature impact embrittlement properties	-	Pass
13	Water vapor permeability coefficient	g.cm/ (cm2.s.Pa)	≦1.0*10-13
14	Dimensional stability	%	±2.0
Note	Technical performance indicators for thickness specifications not listed in the table are required to be performed by interpolation.

The 10m wide 1.5mm HDPE geomembrane is more than just a liner—it is a high-performance barrier system that combines extra-wide coverage, superior strength, and long-term durability. With fewer seams, reliable waterproofing, chemical resistance, and eco-friendly design, it delivers unmatched value to engineers, contractors, and project owners alike.

Whether your project involves protecting the environment, storing water, or containing industrial waste, this geomembrane provides the peace of mind, efficiency, and performance you need. Choosing the right geomembrane is choosing the future of your project—and the 10m wide 1.5mm HDPE geomembrane is the future-proof solution you can trust.
